The modular building allows the creation of flexible and dynamic spaces. This construction system is based on a range of factory-prefabricated modules, forming either single units or assemblable products.
Each three-dimensional module is made from welded steel profiles, forming a frame and including:
| Length ml | Width ml | Height ml | Area m2 | Volume m3 | Weight Kg | ||
|---|---|---|---|---|---|---|---|
| 325 | Ext | 3.17 | 2.50 | 2.76 | 7.93 | 21.87 | 990 |
| Int | 3.03 | 2.33 | 2.30 | 7.06 | 16.24 | ||
| 625 | Ext | 6.17 | 2.50 | 2.76 | 15.43 | 42.57 | 1520 |
| Int | 6.03 | 2.33 | 2.30 | 14.05 | 32.31 | ||
Decking composed of an insulating sandwich panel, 2 steel faces, and a treated waterproof wood panel covered with vinyl flooring or another type of covering upon request.
Galvanized steel ribbed trays.
False ceiling made of sandwich panels, 2 pre-painted steel faces.
Insulating sandwich panel, 2 pre-painted steel faces.
Insulating sandwich panel, 2 pre-painted steel faces.
Windows and doors in aluminum or pre-painted white PVC.
Main panel with switch and residual current circuit breaker.
